- I. IR touch screen description & features
The Infrared touch screen comes with 4 PCB boards inside at each direction, which arrays many tiny Infrared light tubes. These infrared transmission and receiver tubes are one to one correspondence, and come cross the infrared light matrix, arrayed closely at X, Y direction in front of the screen. By constantly scanning to the block object, it detects and locates the user's touch and gesture to the screen.
Feature
1. High stability without drift, free from the affects to time and environment change
2. High suitability free from the interfere of currency, voltage, and static due to the complicated environment
3. High transmittance ¡Ý95%, 100% at max (w/O glass)
4. Long Service Life, endurance, scratch proof
5. Easy Operation No need touch pressure, No demand to touch object
6. IP65 Waterproof, Full sealed design
II. Usage application & environment
2.1Typical Applications
• POS
• ATM
• Desktop touch monitor
• Education Display
• Indoor/outdoor kiosk
• Ticket machine
• In-vehicles and transportation
• Medical instrument
• Industrial control systems
• Gaming machine
2.2 Environment
Operating Temperature: -40¡ãC~70¡ãC
Storage Temperature: -40¡ãC ~80¡ãC
Humidity: Operating 0%-85%, non condensing
Humidity: Storage 0%-95%, non condensing
Elevation: 0-3000meter
Protection Level: IP65, Waterproof, Dust Proof, With Environment Friendly PC Full Sealed Design
Service Life: Above 5 Year
|
Size£º42" 46" 47" 50" 52" 55" 58" 60" 63" 65" 70"75¡± 80" 82" 84"98"
|
|
|
|
¡ö Mechanical Features:
|
|
|
|
Shell Material: Aluminum frame, metal shell
Customization: 46" to 180"
Glass Thickness: 4mm (4mm for 42" above)
Glass Hardness: Mohs 7
|
|
|
|
¡ö Touch Properties:
|
|
|
|
Inductor: Non-transparent object like finger, pen etc.
Location: Contactless infrared Induction positioning technology
Resolution: 4096(W)*4096(D)
Response Time: Multipoint£ºClick£º12ms ;Continuous£º8ms; Single point£ºClick£º 7ms; Continuous£º6ms
Cursor speed: 160 points / sec maximum
The effective touch body size: ¡Ý Ø10mm
Mouse Function: Completely replace the mouse, Support click, double-click, right-click
Positioning Accuracy: 90% regional positioning error: <2mm; edge positioning error <5mm
Multi touch: supporting 2 and 4 points touch
Transmittance: 100%(without glass)£¬88%-92%(with glass)
Service Life of Touching: Unlimited
|
|
|
|
¡ö Electric Parameter :
|
|
|
|
Voltage Range: DC 5.0V¡À5%
Power Consumption: ¨Q1W (200mA DC 5V)
Power Supply Mode: USB supply
ESD: EN61000-4-2£¬Level4£¬Contact discharge at 8KV£¬Air discharge at 15KV
Safety: CE, FCC Class B
Certificate: RoHs
Operating System: WIN8, WIN7, WIN2000 /XP/Vista, Linux, Mac OS, Android
Linking Method: USB2.0 FS£¬driver free
|
|
|
|
¡ö Computer System Requirements :
|
|
|
|
CPU: Pentium III 800£¨Recommend 1GHz 32-bit£¨X86£©Or faster processor£©
Memory: 1GB£¨2GB or more recommended£©for Windows 2000¡¢XP£¬2GB£¨4GB or more recommended£©for Windows Vista¡¢WIN7
Hard Disk: 800MB (including courseware package) room available
|
|
|
|
¡ö Environmental Parameter:
|
|
|
|
Temperature: Working Temperature£º-20 ¡ãC ~ 60 ¡ãC, Storage Temperature£º-30¡ãC ~ 85¡ãC
Humidity: Working Humidity£º20% ~90%, Storage Temperature£º10%~90%
Relative Humidity: 40¡ãC£¬90% RH
External Light Resistance Test: Incandescent lamp (220V,100W) , vertical distance 350mm above, Sunlight luminance: 90000 Lux
Port: USB/PH2.0 5PIN/Customize
Install Mode: Build-in
Workplace: Strong Light, Indoor¡¢Outdoors
Display Type: LED¡¢LCD¡¢PDP and RPT
|
|
|
|
¡ö Packing List :
|
|
|
|
Touch screen£¨including Tempering Glass£©: 1
CD-ROM Drive£¨including whiteboard software£©: 1
Pen: 2
Manual: 1
Warranty Card : 1
5-10 meters USB Cable (optional): 1
|
|
